webchem is a R package to retrieve chemical information from the web. This package interacts with a suite of web APIs to retrieve chemical information.

The functions in the package that hit a specific API have a prefix and suffix separated by an underscore (prefix_suffix()). They follow the format of source_functionality, with the exception of functions that retrieve database identifiers which follow the format of get_identifier. e.g.cs_compinfo uses ChemSpider to retrieve compound informations and get_csid() retrieves ChemSpider IDs.

Currently implemented in webchem

Source Function(s) API Docs API key
Chemical Identifier Resolver (CIR) cir_query() link none
ChemSpider cs_datasources(),cs_name_csid(), cs_element_csid(), cs_convert(), cs_compinfo(), cs_extcompinfo(), cs_prop() link required (link)
PubChem get_cid(), pc_prop(), pc_synonyms() link none
Chemical Translation Service (CTS) cts_convert(), cts_compinfo() none none
PAN Pesticide Database pan_query() none none
Alan Wood’s Compendium of Pesticide Common Names aw_query() none none
PHYSPROP Database pp_query() none none
ETOX get_etoxid(), etox_basic(). etox_targets(), etox_tests() none none
PPDB ppdb_parse() (only parsing) none none
ChemIDplus ci_query() none none
Wikidata get_wdid(), wd_ident() link none
OPSIN opsin_query() link none
Flavornet fn_percept() none none
NIST nist_ri() none none
ChEBI chebi_lite_entity(), chebi_comp_entity() link none

Moreover, there are some functions to check indentifiers: is.inchikey(), is.cas() and is.smiles().

API keys

Some ChemSpider functions require an API key. Please register at RSC (https://developer.rsc.org/) to retrieve an API key.

Installation

Install from CRAN (stable version)

install.packages("webchem")

Install from Github (development version)

install.packages("devtools")
library("devtools")
install_github("ropensci/webchem")

Quickstart

library("webchem")

Chemical Identifier Resolver (CIR)

CAS numbers and molecular weight for Triclosan. Use choices = 1 to return only the first hit.

Query SMILES and InChIKey from CAS (Triclosan). Inputs might by ambiguous and we can specify where to search using resolver=.

Query the number of rings using the InChiKey (Triclosan)

cir_query('XEFQLINVKFYRCS-UHFFFAOYSA-N', 'ring_count')
#> $`XEFQLINVKFYRCS-UHFFFAOYSA-N`
#> [1] 2

ChemSpider

You’ll need a API key:

Retrieve the ChemSpider ID of Triclosan

Use this ID to query information from ChemSpider

Note that the URL of the source if also returned (source_url) and can be used for (micro-)attribution.

Or to convert to a Mol-Object

Note that the Molfile is parsed into a R object (via parse_mol()) and that an API-key is needed

cs_convert() handles a lot of input / output formats:

cs_convert('XEFQLINVKFYRCS-UHFFFAOYAS', from = 'inchikey', to = 'csid', apikey = apikey)
#> $results
#> [1] 5363
#>
#> $limitedToMaxAllowed
#> [1] FALSE
cs_convert('XEFQLINVKFYRCS-UHFFFAOYAS', from = 'inchikey', to = 'inchi', apikey = apikey)
#> [1] "InChI=1/C12H7Cl3O2/c13-7-1-3-11(9(15)5-7)17-12-4-2-8(14)6-10(12)16/h1-6,16H"
cs_convert('c1cc(c(cc1Cl)O)Oc2ccc(cc2Cl)Cl', from = 'smiles', to = 'inchi', apikey = apikey)
#> [1] "InChI=1/C12H7Cl3O2/c13-7-1-3-11(9(15)5-7)17-12-4-2-8(14)6-10(12)16/h1-6,16H"

And get EPISuit predictions from ChemSpider

cs_prop('5363')[['5363']]$epi[ , c(1:4)]

Chemical Translation Service (CTS)

CTS allows to convert from nearly every possible identifier to nearly every possible identifier:

cts_convert(query = '3380-34-5', from = 'CAS', to = 'ChemSpider')
#> $`3380-34-5`
#> [1] "31465"
(inchk <- cts_convert(query = '50-00-0', from = 'CAS', to = 'inchikey'))
#> $`50-00-0`
#> [1] "WSFSSNUMVMOOMR-UHFFFAOYSA-N"

Moreover, we can a lot of information stored in the CTS database using InChIkey

PAN Pesticide Database

pan_query() returns a list of 75 entries, here I extract only 4 of those:

pan_list <- pan_query('lambda-Cyhalothrin', match = 'best')
pan_list[[1]][c("CAS Number", "Chemical Class", "Water Solubility (Avg, mg/L)", "Adsorption Coefficient (Koc)" )]
#> $`CAS Number`
#> [1] "91465-08-6"
#>
#> $`Chemical Class`
#> [1] "Pyrethroid"
#>
#> $`Water Solubility (Avg, mg/L)`
#> [1] NA
#>
#> $`Adsorption Coefficient (Koc)`
#> [1] 157000

ETOX

ETOX: Information System Ecotoxicology and Environmental Quality Targets is a database run by the Federal Environment Agency of Germany and provides data on synonyms, identifiers, Quality Targest and Effects.

First we need to query a substance ID:

get_etoxid tries to find the best match for you (check the matched and distance attributes), if multiple hits are found. Other options are match = 'ask' to enter a interactive mode, 'na' to return NA, 'all' to return all hits and 'first' to return the first hit.

With this substance ID we can query further information from ETOX, e.g.:

Which returns CAS, EC and GSBL numbers, as well as a synonym list.

We can also retrieve Quality Targets:

and results of ecotox tests:

tests <- etox_tests(ids$etoxid)[[1]]
tests$res[ , c('Organism', 'Effect', 'Duration', 'Time_Unit','Endpoint', 'Value', 'Unit')]
#>                           Organism                 Effect Duration
#> 1              Anabaena flos-aquae           not reported        4
#> 2          Brachionus calyciflorus           not reported        2
#> 3          Brachionus calyciflorus           not reported        2
#> 4          Brachionus calyciflorus           not reported        2
#> 5                Brachydanio rerio Embryo-Larval-Toxicity       10
#> 6               Ceriodaphnia dubia              Lethality        7
#> 7               Ceriodaphnia dubia              Mortality        2
#> 8               Ceriodaphnia dubia              Mortality        7
#> 9               Ceriodaphnia dubia           not reported        7
#> 10              Ceriodaphnia dubia           Reproduction        7
#> 11              Ceriodaphnia dubia           Reproduction        7
#> 12                   Daphnia magna              Mortality       21
#> 13                   Daphnia magna           Reproduction       21
#> 14         Desmodesmus subspicatus     Cell Proliferation        4
#> 15          Dunaliella tertiolecta     Cell Proliferation        4
#> 16          Dunaliella tertiolecta     Cell Proliferation        4
#> 17             Oncorhynchus mykiss Embryo-Larval-Toxicity        4
#> 18             Pimephales promelas              Mortality        4
#> 19 Pseudokirchneriella subcapitata       Wachstumshemmung        3
#> 20         Scenedesmus subspicatus                Biomass        3
#> 21         Scenedesmus subspicatus           not reported        4
#> 22         Scenedesmus subspicatus           not reported        4
#> 23         Scenedesmus subspicatus           not reported        4
#> 24         Scenedesmus subspicatus           Reproduction        3
#> 25                 Hyalella azteca              Mortality       10
#>    Time_Unit Endpoint   Value Unit
#> 1          d     NOEC   0.810
#> 2          d     NOEC  50.000 µg/l
#> 3          d     NOEC  50.000 µg/l
#> 4          d     NOEC  50.000 µg/l
#> 5          d     NOEC 200.000 µg/l
#> 6          d     NOEC 339.000 µg/l
#> 7          d     EC50 120.000 µg/l
#> 8          d     NOEC  50.000 µg/l
#> 9          d     NOEC   4.000 µg/l
#> 10         d     NOEC   6.000 µg/l
#> 11         d     NOEC 182.000 µg/l
#> 12         d     NOEC 132.000 µg/l
#> 13         d     NOEC  40.000 µg/l
#> 14         d    ErC50   1.610 µg/l
#> 15         d     NOEC   1.600 µg/l
#> 16         d    EbC50   3.550 µg/l
#> 17         d     NOEC  34.100 µg/l
#> 18         d     LC50 260.000 µg/l
#> 19         d     NOEC   0.200 µg/l
#> 20         d     NOEC   0.500 µg/l
#> 21         d     NOEC   0.690 µg/l
#> 22         d     NOEC   0.742 µg/l
#> 23         d     NOEC   2.380 µg/l
#> 24         d     NOEC   0.500 µg/l
#> 25         d     NOEC   5.000 µg/l

PPDB

The PPDB holds a lot of chemical and ecotoxicological information. Earlier versions of webchem allowed also to search and download the database. However, this is explicitly against the terms and conditions of use. On request we also removed all links to the database.

Therefore, webchem can only provide a function to parse html-code into a R object: parse_ppdb(). However, no examples can be given as saving and downloading the html source is explicitly against the terms and conditions of use.

ChEBI

Chemical Entities of Biological Interest (ChEBI) is a freely available dictionary of molecular entities focused on ‘small’ chemical compounds. chebi_lite_entity() returns a list of data.frames which matching query results. The data.frames contain the chebiid, the chebiiasciiname, a searchscore and entity stars (either 2 or 3, depending on whether the entity was checked thoroughly).

The chebiid can then be used to query the complete ChEBI entity using chebi_comp_entity(). The complete entity contains several different data structures which are returned in a list. The data structures are explained in greater detail at the ChEBI website. Here, the list elements are showcased:

# ecample entities
isoproturon <- chebi_comp_entity(ids$Isoproturon$chebiid[1])
paracetamol <- chebi_comp_entity(ids$`RZVAJINKPMORJF-UHFFFAOYSA-N`$chebiid[1])

# properties: a data.frame with general properties
lapply(isoproturon, '[[', 'properties')
#> $`CHEBI:6049`
#>      chebiid chebiasciiname
#> 1 CHEBI:6049    isoproturon
#>                                                                                                                                                                                                                                                                                                                                                                                                                          definition
#> 1 A member of the class of phenylureas that is 1,1-dimethylurea substituted by a p-cumenyl group at position 3. A selective, systemic herbicide used to control annual grasses and broadleaf weeds in cereals, its use within the EU has been banned after September 2017 on the grounds of potential groundwater contamination and risks to aquatic life; there have also been concerns about its endocrine-disrupting properties.
#>    status                     smiles
#> 1 CHECKED CC(C)c1ccc(NC(=O)N(C)C)cc1
#>                                                                              inchi
#> 1 InChI=1S/C12H18N2O/c1-9(2)10-5-7-11(8-6-10)13-12(15)14(3)4/h5-9H,1-4H3,(H,13,15)
#>                      inchikey charge      mass monoisotopicmass entitystar
#> 1 PUIYMUZLKQOUOZ-UHFFFAOYSA-N      0 206.28410        206.14191          3
# chem_structure: a list of chemical structure formats (e.g. mol)
lapply(isoproturon, '[[', 'chem_structure')
#> $`CHEBI:6049`
#> $`CHEBI:6049`[[1]]
#> $`CHEBI:6049`[[1]]$structure
#> $`CHEBI:6049`[[1]]$structure[[1]]
#> [1] "\n  Mrv0541 11101412262D          \n\n 15 15  0  0  0  0            999 V2000\n    7.5478   -4.8268    0.0000 C   0  0  0  0  0  0  0  0  0  0  0  0\n    7.5478   -4.0026    0.0000 C   0  0  0  0  0  0  0  0  0  0  0  0\n    8.2674   -3.5905    0.0000 C   0  0  0  0  0  0  0  0  0  0  0  0\n    8.9830   -4.0026    0.0000 C   0  0  0  0  0  0  0  0  0  0  0  0\n    8.9830   -4.8268    0.0000 C   0  0  0  0  0  0  0  0  0  0  0  0\n    8.2674   -5.2389    0.0000 C   0  0  0  0  0  0  0  0  0  0  0  0\n    9.6957   -5.2389    0.0000 N   0  0  0  0  0  0  0  0  0  0  0  0\n   10.4117   -4.8310    0.0000 C   0  0  0  0  0  0  0  0  0  0  0  0\n   11.1278   -5.2431    0.0000 N   0  0  0  0  0  0  0  0  0  0  0  0\n   11.8396   -4.8352    0.0000 C   0  0  0  0  0  0  0  0  0  0  0  0\n   10.4076   -4.0068    0.0000 O   0  0  0  0  0  0  0  0  0  0  0  0\n   11.1236   -6.0632    0.0000 C   0  0  0  0  0  0  0  0  0  0  0  0\n    6.8318   -3.5947    0.0000 C   0  0  0  0  0  0  0  0  0  0  0  0\n    6.8318   -2.7746    0.0000 C   0  0  0  0  0  0  0  0  0  0  0  0\n    6.1157   -4.0068    0.0000 C   0  0  0  0  0  0  0  0  0  0  0  0\n  1  2  2  0  0  0  0\n  7  8  1  0  0  0  0\n  2  3  1  0  0  0  0\n  8  9  1  0  0  0  0\n  3  4  2  0  0  0  0\n  9 10  1  0  0  0  0\n  4  5  1  0  0  0  0\n  8 11  2  0  0  0  0\n  5  6  2  0  0  0  0\n  9 12  1  0  0  0  0\n  6  1  1  0  0  0  0\n  2 13  1  0  0  0  0\n 13 14  1  0  0  0  0\n  5  7  1  0  0  0  0\n 13 15  1  0  0  0  0\nM  END\n"
#>
#>
#> $`CHEBI:6049`[[1]]$type
#> $`CHEBI:6049`[[1]]$type[[1]]
#> [1] "mol"
#>
#>
#> $`CHEBI:6049`[[1]]$dimension
#> $`CHEBI:6049`[[1]]$dimension[[1]]
#> [1] "2D"
#>
#>
#> $`CHEBI:6049`[[1]]$defaultStructure
#> $`CHEBI:6049`[[1]]$defaultStructure[[1]]
#> [1] "true"
# synonyms: a data.frame of synonyms (collected from different sources)
lapply(isoproturon, '[[', 'synonyms')
#> $`CHEBI:6049`
#>                                      data    type                 source
#> 1 1,1-dimethyl-3-(p-isopropylphenyl)-urea SYNONYM NIST Chemistry WebBook
#> 2            3-p-cumenyl-1,1-dimethylurea SYNONYM Alan Wood's Pesticides
#> 3    N-4-isopropylphenyl-N,N-dimethylurea SYNONYM NIST Chemistry WebBook
# iupacnames: a data.frame of IUPAC names (collected from different sources)
lapply(isoproturon, '[[', 'iupacnames')
#> $`CHEBI:6049`
#>                                         data       type source
#> 1 1,1-dimethyl-3-[4-(propan-2-yl)phenyl]urea IUPAC NAME  IUPAC
# formulae: a data.frame of chemical formulae (collected from different sources)
lapply(isoproturon, '[[', 'formulae')
#> $`CHEBI:6049`
#>        data source
#> 1 C12H18N2O  ChEBI
# regnumbers: a data.frame of registry numbers (e.g. CAS, Beilstein, Reaxys) (collected from different sources)
lapply(isoproturon, '[[', 'regnumbers')
#> $`CHEBI:6049`
#>         data                   type                 source
#> 1    2214033 Reaxys Registry Number                 Reaxys
#> 2 34123-59-6    CAS Registry Number          KEGG COMPOUND
#> 3 34123-59-6    CAS Registry Number NIST Chemistry WebBook
#> 4 34123-59-6    CAS Registry Number             ChemIDplus
# chebiid_snd: a data.frame with secondary ChEBI ids
lapply(paracetamol, '[[', 'chebiid_snd')
#> $`CHEBI:46195`
#>      chebiids
#> 1 CHEBI:46191
#> 2  CHEBI:2386
# citations: Publications which cite the entity along with hyperlinks to the PubMed entry via Europe PMC
head(lapply(paracetamol, '[[', 'citations')[[1]])
#>       data            type     source
#> 1 11084378 PubMed citation Europe PMC
#> 2 11304127 PubMed citation Europe PMC
#> 3 16716555 PubMed citation Europe PMC
#> 4 18953082 PubMed citation Europe PMC
#> 5 21108564 PubMed citation Europe PMC
#> 6 22770225 PubMed citation Europe PMC
# parents: parent ontologies of the entity
lapply(paracetamol, '[[', 'parents')
#> $`CHEBI:46195`
#>                               chebiName     chebiId                  type
#> 1            cyclooxygenase 2 inhibitor CHEBI:50629              has role
#> 2            cyclooxygenase 1 inhibitor CHEBI:50630              has role
#> 3                non-narcotic analgesic CHEBI:35481              has role
#> 4                           antipyretic CHEBI:35493              has role
#> 5  non-steroidal anti-inflammatory drug CHEBI:35475              has role
#> 6                               phenols CHEBI:33853                  is a
#> 7                         4-aminophenol CHEBI:17602 has functional parent
#> 8                            xenobiotic CHEBI:35703              has role
#> 9                     hepatotoxic agent CHEBI:50908              has role
#> 10         human blood serum metabolite CHEBI:85234              has role
#> 11           cyclooxygenase 3 inhibitor CHEBI:73263              has role
#> 12            environmental contaminant CHEBI:78298              has role
#> 13                           acetamides CHEBI:22160                  is a
#>     status cyclicRelationship
#> 1  CHECKED              false
#> 2  CHECKED              false
#> 3  CHECKED              false
#> 4  CHECKED              false
#> 5  CHECKED              false
#> 6  CHECKED              false
#> 7  CHECKED              false
#> 8  CHECKED              false
#> 9  CHECKED              false
#> 10 CHECKED              false
#> 11 CHECKED              false
#> 12 CHECKED              false
#> 13 CHECKED              false
# children: child ontologies of the entity
lapply(paracetamol, '[[', 'children')
#> $`CHEBI:46195`
#>                                              chebiName      chebiId
#> 1                  acetaminophen glutathione conjugate  CHEBI:32639
#> 2                   2-methoxyacetaminophen glucuronide CHEBI:133005
#> 3  S-(5-acetamido-2-hydroxyphenyl)-N-acetyl-L-cysteine CHEBI:133435
#> 4                                           methacetin CHEBI:139354
#> 5                                           phenacetin   CHEBI:8050
#> 6              S-(5-acetamido-2-hydroxyphenyl)cysteine CHEBI:133066
#> 7           acetaminophen O-beta-D-glucosiduronic acid  CHEBI:32636
#> 8                                 3-nitroacetaminophen CHEBI:139475
#> 9                             3-nitroacetaminophen-TMS CHEBI:139476
#> 10                                 paracetamol sulfate  CHEBI:32635
#>                     type  status cyclicRelationship
#> 1  has functional parent CHECKED              false
#> 2  has functional parent CHECKED              false
#> 3  has functional parent CHECKED              false
#> 4  has functional parent CHECKED              false
#> 5  has functional parent CHECKED              false
#> 6  has functional parent CHECKED              false
#> 7  has functional parent CHECKED              false
#> 8  has functional parent CHECKED              false
#> 9  has functional parent CHECKED              false
#> 10 has functional parent CHECKED              false
# dblinks: Links to other data bases
lapply(paracetamol, '[[', 'dblinks')
#> $`CHEBI:46195`
#>            data                    type
#> 1            52  Drug Central accession
#> 2 Acetaminophen     Wikipedia accession
#> 3        C06804 KEGG COMPOUND accession
#> 4      CPD-7669       MetaCyc accession
#> 5        D00217     KEGG DRUG accession
#> 6       DB00316      DrugBank accession
#> 7   HMDB0001859          HMDB accession
#> 8      LSM-5533         LINCS accession
#> 9           TYL      PDBeChem accession
# comments: General comment(s)
lapply(paracetamol, '[[', 'comments')
#> $`CHEBI:46195`
#>                                                                             text
#> 1 Stravs M, Schymanski E, Singer H, Department of Environmental Chemistry, Eawag
#>         date
#> 1 2014-10-29
# Metabolites of Species
head(lapply(paracetamol, '[[', 'origins')[[1]])
#>    speciesText speciesAccession   SourceType SourceAccession
#> 1 Mus musculus   NCBI:txid10090 MetaboLights        MTBLS292
#> 2 Homo sapiens    NCBI:txid9606    PubMed Id        19309105
#> 3 Homo sapiens    NCBI:txid9606    PubMed Id        18502700
#> 4 Homo sapiens    NCBI:txid9606    PubMed Id        12097436
#> 5 Homo sapiens    NCBI:txid9606    PubMed Id        21359215
#> 6 Homo sapiens    NCBI:txid9606 MetaboLights         MTBLS90
#>         componentText componentAccession
#> 1                <NA>               <NA>
#> 2               urine        BTO:0001419
#> 3 cerebrospinal fluid     UBERON:0001359
#> 4              saliva     UBERON:0001836
#> 5               blood     UBERON:0000178
#> 6         blood serum        BTO:0000133

Misc functions

Check if a string is a valid CAS registry number
is.cas('64-17-5')
#> [1] TRUE
is.cas('64-17-6')
#> [1] FALSE
Check if a string is a valid InChIKey

Using a pure R implementation:

is.inchikey('BQJCRHHNABKAKU-KBQPJGBKSA-N')
#> [1] TRUE
is.inchikey('BQJCRHHNABKAKU-KBQPJGBKXA-N')
#> [1] FALSE

Using the ChemSpider API

is.inchikey('BQJCRHHNABKAKU-KBQPJGBKSA-N', type = 'chemspider')
#> [1] TRUE
is.inchikey('BQJCRHHNABKAKU-KBQPJGBKXA-N', type = 'chemspider')
#> [1] FALSE
Check if a string is a valid SMILES
is.smiles('Clc(c(Cl)c(Cl)c1C(=O)O)c(Cl)c1Cl')
# 'J' is not found in the periodic table
is.smiles('Clc(c(Cl)c(Cl)c1C(=O)O)c(Cl)c1ClJ')

Acknowledgements

Without the fantastic web services webchem wouldn’t be here. Therefore, kudos to the web service providers and developers!

Want to contribute?

Check out our contribution guide here.

Meta

ropensci
