writexl

Portable, light-weight data frame to xlsx exporter based on libxlsxwriter. No Java or Excel required.

Wraps the libxlsxwriter library to create files in Microsoft Excel ‘xlsx’ format.

Installation

install.packages("writexl")

Getting started

# A tibble: 150 × 5
   Sepal.Length Sepal.Width Petal.Length Petal.Width Species
          <dbl>       <dbl>        <dbl>       <dbl> <chr>
 1          5.1         3.5          1.4         0.2 setosa
 2          4.9         3            1.4         0.2 setosa
 3          4.7         3.2          1.3         0.2 setosa
 4          4.6         3.1          1.5         0.2 setosa
 5          5           3.6          1.4         0.2 setosa
# ℹ 145 more rows

A named list writes one sheet per element:

write_xlsx(list(Flowers = iris, Cars = mtcars))

That is the whole of the common case. Everything below is optional.

What else it can do

Each of these has a vignette; none is needed to write a workbook.

Formatting cells Fonts, fills, borders, number formats and alignment, built from group constructors that combine with +. The same format object styles a cell, a column, a chart series or a conditional rule. Conditional formatting, colour scales, data bars and icon sets.
Worksheets and workbooks Column widths and row heights in characters or pixels, frozen and split panes, tab colours and visibility, outlines, protection, page setup and printing, document properties, and the row-streaming mode for large workbooks.
Charts and images All 22 chart types Excel offers, with axes, markers, data labels, trendlines, error bars, legends and data tables; chartsheets; and pictures placed on a sheet, inside a cell, in a header or tiled behind the grid.
Formulas, tables and the rest Formulas including array and dynamic array formulas, hyperlinks, comments, rich strings, mixed-type columns, data validation, autofilters that actually hide the rows, worksheet tables and merged cells.
Everything at once One runnable script that exercises the whole package into two workbooks — the quickest way to see what it does without reading the other four.

A taste of how they fit together:

sheet <- xl_sheet(
  sales,
  cols   = xl_col_spec("revenue", format = xl_num_format("$#,##0")),
  freeze = "A2",
  chart  = xl_chart("column", xl_chart_series(values = list(cols = "revenue")))
)
write_xlsx(list(Sales = sheet), "report.xlsx")

Round-tripping

Every column type survives a trip through readxl unchanged, with one exception that is deliberate:

library(nycflights13)
out <- readxl::read_xlsx(writexl::write_xlsx(flights))
keep <- setdiff(names(flights), "time_hour")
all.equal(out[keep], flights[keep])
## TRUE

time_hour is a POSIXct in America/New_York, and Excel has no concept of a time zone. Rather than silently converting everything to UTC, writexl decides once per workbook: when every datetime shares a zone it writes the local wall-clock reading and drops the ” UTC” suffix from the default datetime format, so nothing is mislabelled; when the zones differ it converts to UTC and warns. Either way the zone itself is not in the file for readxl to hand back.

Performance

Writing nycflights13::flights — 336,776 rows by 19 columns — is faster than the openxlsx2 implementation, for files of the same size:

library(nycflights13)
bench <- function(f) median(replicate(2, {
  p <- tempfile(fileext = ".xlsx")
  on.exit(unlink(p))
  system.time(f(p))[["elapsed"]]
}))

bench(function(p) writexl::write_xlsx(flights, p))
## 12.3
bench(function(p) openxlsx2::write_xlsx(flights, p))
## 19.6

The output files are within a rounding error of each other:

file.size(writexl::write_xlsx(flights, tempfile(fileext = ".xlsx")))
## 29132216   (27.8 MB)

p <- tempfile(fileext = ".xlsx"); openxlsx2::write_xlsx(flights, p); file.size(p)
## 29297097   (27.9 MB)

Measured on R 4.6.1, writexl 2.0.0, openxlsx2 1.28.

Memory

constant_memory = TRUE streams each row to disk instead of holding the whole sheet, which is the difference between a workbook that fits in memory and one that does not. Peak resident memory of the whole R process, writing the same 336,776 rows:

peak memory file time
constant_memory = FALSE 894 MB 26.8 MB 7.4 s
constant_memory = TRUE 208 MB 27.8 MB 7.7 s

A quarter of the memory, for a file 3.5% larger and about the same time. Streaming produces slightly bigger files because a shared-string table cannot be built for rows already flushed to disk.

Left at its default, writexl chooses per workbook: streaming is switched on only when the estimated saving is worth it, and switched off automatically for the features that cannot be written while streaming — worksheet tables, multi-cell array formulas, merged ranges and embedded images. See Worksheets and workbooks.
