ghql - a GraphQL client for R

GraphQL - https://graphql.org

Examples of GraphQL APIs:

Other GraphQL R packages:

  • graphql - GraphQL query parser
  • gqlr - GraphQL server and query methods

GitHub Authentication

Note: To be clear, this R package isn’t just for the GitHub GraphQL API, but it is the most public GraphQL API we can think of, so is used in examples throughout here.

See https://docs.github.com/en/graphql/guides/forming-calls-with-graphql#authenticating-with-graphql for getting an OAuth token.

Store the token in a env var called GITHUB_GRAPHQL_TOKEN

Install

CRAN version

Development version

remotes::install_github("ropensci/ghql")

initialize client

token <- Sys.getenv("GITHUB_GRAPHQL_TOKEN")
con <- GraphqlClient$new(
  url = "https://api.github.com/graphql",
  headers = list(Authorization = paste0("Bearer ", token))
)

load schema

Since not every GraphQL server has a schema at the base URL, have to manually load the schema in this case

con$load_schema()

Queries

Make a Query class object

qry <- Query$new()

When you construct queries we check that they are properly formatted using the graphql package that leverages the libgraphqlparser C++ parser. If the query is malformed, we return a message as to why the query is malformed.

Get some stargazer counts

qry$query('mydata', '{
  repositoryOwner(login:"sckott") {
    repositories(first: 5, orderBy: {field:PUSHED_AT,direction:DESC}, isFork:false) {
      edges {
        node {
          name
          stargazers {
            totalCount
          }
        }
      }
    }
  }
}')
qry
#> <ghql: query>
#>   queries:
#>     mydata
qry$queries$mydata
#>
#>  {
#>   repositoryOwner(login:"sckott") {
#>     repositories(first: 5, orderBy: {field:PUSHED_AT,direction:DESC}, isFork:false) {
#>       edges {
#>         node {
#>           name
#>           stargazers {
#>             totalCount
#>           }
#>         }
#>       }
#>     }
#>   }
#> }
# returns json
(x <- con$exec(qry$queries$mydata))
#> [1] "{\"data\":{\"repositoryOwner\":{\"repositories\":{\"edges\":[{\"node\":{\"name\":\"Headstart\",\"stargazers\":{\"totalCount\":134}}},{\"node\":{\"name\":\"makeregistry\",\"stargazers\":{\"totalCount\":3}}},{\"node\":{\"name\":\"itis-lookup\",\"stargazers\":{\"totalCount\":0}}},{\"node\":{\"name\":\"SSOAP\",\"stargazers\":{\"totalCount\":1}}},{\"node\":{\"name\":\"gbifrb\",\"stargazers\":{\"totalCount\":2}}}]}}}}\n"
# parse to an R list
jsonlite::fromJSON(x)
#> $data
#> $data$repositoryOwner
#> $data$repositoryOwner$repositories
#> $data$repositoryOwner$repositories$edges
#>      node.name node.totalCount
#> 1    Headstart             134
#> 2 makeregistry               3
#> 3  itis-lookup               0
#> 4        SSOAP               1
#> 5       gbifrb               2

Parameterize a query by a variable

Define a query

qry <- Query$new()
qry$query('getgeninfo', 'query getGeneInfo($genId: String!){
  geneInfo(geneId: $genId) {
    id
    symbol
    chromosome
    start
    end
    bioType
    __typename
  }
}')

Define a variable as a named list

variables <- list(genId = 'ENSG00000137033')

Creat a clint and make a request, passing in the query and then the variables

con <- GraphqlClient$new('https://genetics-api.opentargets.io/graphql')
res <- con$exec(qry$queries$getgeninfo, variables)
jsonlite::fromJSON(res)
#> $data
#> $data$geneInfo
#> $data$geneInfo$id
#> [1] "ENSG00000137033"
#>
#> $data$geneInfo$symbol
#> [1] "IL33"
#>
#> $data$geneInfo$chromosome
#> [1] "9"
#>
#> $data$geneInfo$start
#> [1] 6215786
#>
#> $data$geneInfo$end
#> [1] 6257983
#>
#> $data$geneInfo$bioType
#> [1] "protein_coding"
#>
#> $data$geneInfo$`__typename`
#> [1] "Gene"

Example: Datacite

Datacite provides DOIs for research data. Check out the Datacite GraphQL docs to get started. A minimal example:

con <- GraphqlClient$new("https://api.datacite.org/graphql")
qry <- Query$new()
qry$query('dc', '{
  publications(query: "climate") {
    totalCount

    nodes {
      id
      titles {
        title
      }
      descriptions {
        description
      }
      creators {
        name
        familyName
      }
      fundingReferences {
        funderIdentifier
        funderName
        awardTitle
        awardNumber
      }
    }
  }
}')
res <- con$exec(qry$queries$dc)
head(jsonlite::fromJSON(res)$data$publications$nodes)
#>                                     id
#> 1 https://doi.org/10.4122/1.1000000046
#> 2 https://doi.org/10.4122/1.1000000047
#> 3 https://doi.org/10.4122/1.1000000048
#> 4 https://doi.org/10.4122/1.1000000054
#> 5 https://doi.org/10.4122/1.1000000055
#> 6 https://doi.org/10.4122/1.1000000056
#>                                                     titles
#> 1                    Single Cell Protein from Landfill Gas
#> 2                    Single Cell Protein from Landfill Gas
#> 3                    Single Cell Protein from Landfill Gas
#> 4                        Reengineering of Tietgenkollegiet
#> 5                        Reengineering of Tietgenkollegiet
#> 6 Reengineering of Tietgen Kollegiet into a green building
#>                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                       descriptions
#> 1 Municipal solid waste (MSW) landfills are one of the largest human-generated sources of methane emissions in the United States and other countries globally. Methane is believed to be a very potent greenhouse gas that is a key contributor to global climate change, over 21 times stronger than CO2. Methane also has a short (10-year) atmospheric life. Because methane is both potent and short-lived, reducing methane emissions from MSW landfills is one of the best ways to achieve a near-term beneficial impact in mitigating global climate change. The United States Environmental Protection Agency estimates that a landfill gas (LFG) project will capture roughly 60-90% of the methane emitted from the landfill, depending on system design and effectiveness. The captured methane can be then purified and used for industrial applications, as in this case the production of SCP. Utilizing methane in this way decreases its demand from fossil fuels which is its traditional source.
#> 2 Municipal solid waste (MSW) landfills are one of the largest human-generated sources of methane emissions in the United States and other countries globally. Methane is believed to be a very potent greenhouse gas that is a key contributor to global climate change, over 21 times stronger than CO2. Methane also has a short (10-year) atmospheric life. Because methane is both potent and short-lived, reducing methane emissions from MSW landfills is one of the best ways to achieve a near-term beneficial impact in mitigating global climate change. The United States Environmental Protection Agency estimates that a landfill gas (LFG) project will capture roughly 60-90% of the methane emitted from the landfill, depending on system design and effectiveness. The captured methane can be then purified and used for industrial applications, as in this case the production of SCP. Utilizing methane in this way decreases its demand from fossil fuels which is its traditional source.
#> 3 Municipal solid waste (MSW) landfills are one of the largest human-generated sources of methane emissions in the United States and other countries globally. Methane is believed to be a very potent greenhouse gas that is a key contributor to global climate change, over 21 times stronger than CO2. Methane also has a short (10-year) atmospheric life. Because methane is both potent and short-lived, reducing methane emissions from MSW landfills is one of the best ways to achieve a near-term beneficial impact in mitigating global climate change. The United States Environmental Protection Agency estimates that a landfill gas (LFG) project will capture roughly 60-90% of the methane emitted from the landfill, depending on system design and effectiveness. The captured methane can be then purified and used for industrial applications, as in this case the production of SCP. Utilizing methane in this way decreases its demand from fossil fuels which is its traditional source.
#> 4                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                     Integrated functional design project containing reengineering of Tietgenkollegiet. The purpose is to meet the requirements of low energy class 1, and a satisfying inddor air climate and level of daylight.
#> 5                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                     Integrated functional design project containing reengineering of Tietgenkollegiet. The purpose is to meet the requirements of low energy class 1, and a satisfying inddor air climate and level of daylight.
#> 6                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                      Reengineering of Tietgen Kollegiet into a green building in terms of energy consumption and indoor climate.
#>                                                                                                                                            creators
#> 1                                                                                 Babi, Deenesh, Price, Jason, Woodley, Prof. John, Babi, Price, NA
#> 2                                                                                 Babi, Deenesh, Price, Jason, Woodley, Prof. John, Babi, Price, NA
#> 3                                                                                 Babi, Deenesh, Price, Jason, Woodley, Prof. John, Babi, Price, NA
#> 4                           Chaachouh, Hassan Valid, Pedersen, Stine Holst, Alilou, Zahra, Hvid, Christian Anker, Chaachouh, Pedersen, Alilou, Hvid
#> 5                           Chaachouh, Hassan Valid, Pedersen, Stine Holst, Alilou, Zahra, Hvid, Christian Anker, Chaachouh, Pedersen, Alilou, Hvid
#> 6 Løvborg, Daniel, Holck, Jakob Trier, Sørensen, Jannie Bakkær, Birkemose, Stig, Hviid, Christian Anker, Løvborg, Holck, Sørensen, Birkemose, Hviid
#>   fundingReferences
#> 1              NULL
#> 2              NULL
#> 3              NULL
#> 4              NULL
#> 5              NULL
#> 6              NULL

Example: Countries Data

A public GraphQL API for information about countries, continents, and languages. This project uses Countries List and provinces as data sources, so the schema follows the shape of that data, with a few exceptions:

Link to the GraphQL schema api

link <- 'https://countries.trevorblades.com/'

Create a new graphqlClient object

con <- GraphqlClient$new(url = link)

Define a Graphql Query

query <- '
query($code: ID!){
  country(code: $code){
    name
    native
    capital
    currency
    phone
    languages{
      code
      name
    }
  }
}'

The ghql query class and define query in a character string

new <- Query$new()$query('link', query)

Inspecting the schema

new$link
#>
#>
#> query($code: ID!){
#>   country(code: $code){
#>     name
#>     native
#>     capital
#>     currency
#>     phone
#>     languages{
#>       code
#>       name
#>     }
#>   }
#> }

define a variable as a named list

variable <- list(
  code = "DE"
)

Making a request, passing in the query and then the variables. Then you convert the raw object to a structured json object

result <- con$exec(new$link, variables = variable) %>%
  fromJSON(flatten = FALSE)
result
#> $data
#> $data$country
#> $data$country$name
#> [1] "Germany"
#>
#> $data$country$native
#> [1] "Deutschland"
#>
#> $data$country$capital
#> [1] "Berlin"
#>
#> $data$country$currency
#> [1] "EUR"
#>
#> $data$country$phone
#> [1] "49"
#>
#> $data$country$languages
#>   code   name
#> 1   de German

Convert the json data into a tibble object

country_data <- result$data$country %>%
  as_tibble()
country_data
#> # A tibble: 1 x 6
#>   name    native      capital currency phone languages$code $name
#>   <chr>   <chr>       <chr>   <chr>    <chr> <chr>          <chr>
#> 1 Germany Deutschland Berlin  EUR      49    de             German

run a local GraphQL server

(con <- GraphqlClient$new("http://localhost:4000/graphql"))
#> <ghql client>
#>   url: http://localhost:4000/graphql
xxx <- Query$new()
xxx$query('query', '{
  __schema {
    queryType {
      name,
      fields {
        name,
        description
      }
    }
  }
}')
con$exec(xxx$queries$query)
#> $data
#> $data$`__schema`
#> $data$`__schema`$queryType
#> $data$`__schema`$queryType$name
#> [1] "Query"
#>
#> $data$`__schema`$queryType$fields
#>    name description
#> 1 hello
#> 2  name
